16x04 COB Character LCD Module Monochrome STN ST7066/AIP31066 IIC Interface 87x60mm
This industrial grade 16x4 character LCD module adopts advanced COB (Chip On Board) packaging design with monochrome STN transmissive display effect, driven by professional ST7066 or AIP31066 controller IC. It features 16(characters)*4(lines) standard display format, IIC (I2C) interface and compact module dimension (87.0mm(W)*60.0mm(H)*12.9mm(T)). With stable performance and high reliability, it is widely applied in industrial control, measuring instruments, smart home appliances, embedded systems and various monochrome display scenarios.
Product Specifications
| Display Type |
Monochrome COB Character LCD Module (STN, Transmissive) |
| Model No. |
YMC1604SB-X01 |
| Part No. |
1604A |
| Display Format |
16(characters) * 4(lines) |
| Dots |
16*04 |
| Controller IC |
ST7066 / AIP31066 |
| Connection Type |
COB (Chip On Board) |
| Interface Type |
IIC (I2C) |
| Module Dimension |
87.0mm(W) * 60.0mm(H) * 12.9mm(T) |
| LCD AA (Viewing Area) |
55.40mm(W) * 15.74mm(H) |
| Iron Frame (W) |
62.00mm |
| PCB Dimension |
87.00mm(W) * 60.00mm(H) |
Product Features
16*4 character COB packaging design with monochrome STN transmissive display, providing clear and stable character presentation. Professional ST7066 or AIP31066 controller IC, ensuring stable driving performance and high compatibility with various embedded systems. IIC (I2C) interface design, simple circuit connection and low pin occupation, suitable for space-limited electronic product design. Compact module size (87.0*60.0*12.9mm), standard mechanical dimension for easy installation and replacement in various electronic devices. Precise mechanical parameters, ensuring stable assembly and reliable operation in long-term application scenarios. Industrial grade quality, high structural reliability and durability ideal for industrial control and instrument applications.
Product Color Options
- Gray Mode (Gray Film)
- Blue Mode (Blue Film)
- Yellow-Green Mode (Yellow-Green Film)
Company Profile
Shenzhen Yingzhanying Technology Co., Ltd. was founded in January 2018 and is located in Shenzhen, China—a global hub of the electronics industry. Its predecessor is Shenzhen Shengyuan Optoelectronics Co., Ltd., established in 2013. The company has always been committed to custom services, R&D, sales and after-sales services in the optoelectronic display industry.
The company's products include Liquid Crystal Display (LCD) modules (LCM), touch modules, LCD panels, FPC (Flexible Printed Circuit) boards and various optoelectronic materials. These products are widely used in industrial control, medical equipment, handheld devices, instruments and meters, automotive electronics, digital wearables, household appliances, financial services and other fields, making it a supplier to many well-known clients worldwide.
Frequently Asked Questions
1. How do you control product quality?
Each item undergoes strict testing before shipping to ensure reliability and performance.
2. Do you supply samples?
Yes, we provide samples for evaluation.
3. What is the delivery time?
Typically 7 working days after payment confirmation.
4. What is the minimum order quantity?
1 piece minimum order quantity.
5. What if we receive missing or defective items?
Please contact us immediately, and we will investigate to provide the best solution promptly.
6. What are your main products?
Comprehensive range including, LCD modules, touch modules, LCD panels, FPC boards and various optoelectronic materials for industrial control, medical equipment and smart devices.
7. What payment methods do you accept?
We accept T/T (Telegraphic Transfer) payments.
8. What shipping methods do you offer?
DHL and China Post shipping services available.
